Description
The DS 800×4 is synonymous with multichannel amplifier. It has 4 channels of 200 Watts RMS, with a maximum power of 800 Watts RMS, at 1,2 ohms and is compatible with any frequency, that is to say, it is a FULL RANGE amp. Versatility, efficiency and quality in a single product.
| OPERATION CLASS | D |
|---|---|
| NUMBER OF CHANNELS | 04 |
| MAXIMUM POWER | @ 12.6 VDC - 1 OHM: 800W RMS (4 x 200W RMS) @ 12.6 VDC - 2 OHMS: 544W RMS (4 x 136W RMS) 2 bridgeable channels - 1 OHM: 800WRMS (2 x 400WRMS) |
| INPUT SENSITIVITY | 250mV |
| SIGNAL TO NOISE RATIO | >88dB |
| FREQUENCY RESPONSE | 10Hz to 36KHz(-3dB) |
| CROSSOVER HIGH PASS (HPF) | 90Hz (-12dB/8th) Fixed |
| CROSSOVER LOW PASS (LPF) | 90Hz (-12dB/8th) Fixed |
| INPUT IMPEDANCE | 18K Ohms |
| OUTPUT IMPEDANCE | 1 Ohm |
| PROTECTION SYSTEM | Output overload |
| MIN. SUPPLY VOLTAGE | 9VDC |
| MAXIMUM POWER SUPPLY VOLTAGE | 16VDC |
| CONSUMPTION AT REST | 1,0A |
| MAXIMUM MUSIC CONSUMPTION | @12.6VDC: 51A |
| MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL | 102A |
| DIMENSIONS (WXHXD) | 7.17" x 2.05" x 8.94" (173 x 52 x 227mm) |
| WEIGHT | 3.52lb (1,43kg) |
| EAN | 7898556844826 |
| OPERATION CLASS | Class D |
|---|---|
| NUMBER OF CHANNELS | 04 |
| MAXIMUM POWER | @ 12.6 VDC - 2 OHMS: 800W RMS (4 x 200W RMS) @ 12.6 VDC - 4 OHMS: 544W RMS (4 x 136W RMS) 2 bridgeable channels - 2 OHMS: 800WRMS (2 x 400WRMS) |
| INPUT SENSITIVITY | 250mV |
| SIGNAL TO NOISE RATIO | >88dB |
| FREQUENCY RESPONSE | 10Hz to 36KHz (-3dB) |
| CROSSOVER HIGH PASS (HPF) | 90Hz (-12dB/8ª) Fixed |
| CROSSOVER LOW PASS (LPF) | 90Hz (-12dB/8ª) Fixed |
| INPUT IMPEDANCE | 18K Ohms |
| OUTPUT IMPEDANCE | 2 Ohms |
| PROTECTION SYSTEM | Output overload |
| MIN. SUPPLY VOLTAGE | 9VDC |
| MAXIMUM POWER SUPPLY VOLTAGE | 16VDC |
| CONSUMPTION AT REST | 1.4A |
| MAXIMUM MUSIC CONSUMPTION | @12.6VDC: 43A |
| MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL | 86A |
| DIMENSIONS (WXHXD) | 7.17" x 2.05" x 8.94" (173 x 52 x 227mm) |
| WEIGHT | 3.52lb (1,43kg) |
| EAN | 7898556844369 |
